Thermal Receipt Printers > 80mm Thermal Printer >

Q833L

Brand name: Xprinter
Place of Origin: China
Model Number: XP-Q833L
Material: ABS
Certification: CCC, CE, FCC, RoHS, KC, SAA, BIS, BSMI
OEM Availability: Yes
Payment Term: T/T, L/C
EMAIL INQUIRY

Product Overview

● 230, 260mm/s low noise, high speed printing	● Small size and low power consumption
● Support wall hanging function	● Support queuing function
● Support IAP online upgrade

Product Specification

Printing
Printing method	Direct thermal
Media width	79.5±0.5mm / φ 80 mm
Print width	72mm
Column capacity	576 dots/line or 512 dots/line
Printing speed	230mm/s	260mm/s
Interface	USB / USB+Serial / USB+Lan / (Optional: Bluetooth/Wifi)	USB+Serial+Lan (Optional: Bluetooth/Wifi)
Line spacing	3.75mm (Adjustable by commands)
Character size	ANK，Font A：1.5×3.0mm（12×24 dots） Font B：1.1×2.1mm（9×17 dots） Chinese,traditional Chinese:3.0×3.0mm（24×24 dots）
Barcode Character
Extension character sheet	PC347（Standard Europe）、Katakana、PC850（Multilingual）、PC860（Portuguese）、PC863（Canadian-French）、PC865（Nordic）、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866（Cyrillic#2）、PC852（Latin2）、PC858、IranII、Latvian、Arabic、PT151（1251）
1D Barcode	UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/CODABAR/CODE93/CODE128
2D Barcode	QR CODE: Lan / USB+Lan	QR CODE / PDF417
Input buffer	128 Kbytes: USB+Serial / USB / USB+Bluetooth/USB+WiFi 256 Kbytes: Lan / USB+Lan / USB+Serial+Lan
NV Flash	256 Kbytes
Power
Power adaptor	Input: AC 100V/240V, 50～60Hz; Output：DC 24V/2.5A
Printer input	DC 24V/2.5A
Cash drawer	DC 24V/1A
Physical characteristics
Weight	0.87 KG
Dimensions	180145130mm (D×W×H)
Environmental Requirements
Work environment	Temperature (0～45℃) humidity(10～80%)
Storage environment	Temperature(-10～60℃) humidity(10～90%)
Reliability
Auto cutter	Partial
Cutter life	1.5 million cuts
Printer head life	150 KM
Software
Emulation	ESC / POS
Driver	Windows / Linux / Mac OS / Android
