Product Specification
Model | XP-C590H |
Printing Features | |
Printing method | Direct thermal |
Paper width | 57.5±0.5mm |
Print width | 48 mm |
Column capacity | 384 dots/line |
Print speed | 120 mm/s |
Interface | USB / USB+Bluetooth / USB+Lan |
Line spacing | 3.75mm (Adjustable by commands) |
Fonts Symbology | |
Character size | Afont A: 12x24, Font B: 9x17, CHN: 24*24 |
Barcode types | UPC-A / UPC-E / JAN13(EAN13) / JAN8(EAN8) / CODE39 / ITF / CODABAR / CODE93 / CODE128 / QR code |
Extended character sheet | PC347(Standard Europe) / Katakana / PC850(Multilingual) / PC860(Portuguese) / PC863(Canadian-French) / PC865(Nordic) / West Europe / Greek / Hebrew / East Europe / Iran / WPC1252 / PC866(Cyrillic#2) / PC852(Latin2) / PC858 / IranII / Latvian / Arabic / PT151(1251) |
Input buffer | USB/USB+BT: 128 Kbytes | USB+Lan: 256 Kbytes |
NV Flash | 1M bytes |
Power | |
Power adaptor | AC 100V/240V, 50~60Hz |
Power source | DC 9V / 2A |
Cash drawer | DC 12V / 1A |
Physical characteristics | |
Weight | 0.7kg |
Dimensions | 120 ×110 × 113mm |
Environmental Conditions | |
Operation environment | Temperature (0~45℃) humidity(10~80%) |
Storage environment | Temperature(-10~60℃) humidity(10~90%) |
Physical Reliability | |
Printer head life | 50KM |
Software | |
Emulation | ESC/POS |
Driver | Windows/JPOS/Linux/Android/Mac |
SDK | iOS / Android / Windows |
