  • 58 printer without hand tearing
    Long-life wear-resistant thickened automatic cutter
    Large gear configuration, ultra-long service life
    120 mm/s low noise, high speed printing
    Standard Chinese simplified GB18030 large font
  • EMAIL   INQUIRY

Product Specification



ModelXP-Q90EC
Printing Features
Printing methodDirect thermal
Paper width
57.5±0.5mm
Print width48 mm
Column capacity384 dots/line
Print speed120 mm/s
InterfaceUSB / USB+Bluetooth / USB+Lan / LAN / RS232
Line spacing3.75mm (Adjustable by commands)
Fonts Symbology
Character sizeAfont A: 12x24, Font B: 9x17, CHN: 24*24
Barcode types

UPC-A / UPC-E / JAN13(EAN13) / JAN8(EAN8) / CODE39 / ITF / CODABAR / CODE93 / CODE128 / QR code

Extended character sheet

PC347(Standard Europe) / Katakana / PC850(Multilingual) / PC860(Portuguese) / PC863(Canadian-French) / PC865(Nordic) / West Europe / Greek / Hebrew / East Europe / Iran / WPC1252 / PC866(Cyrillic#2) / PC852(Latin2) / PC858 / IranII / Latvian / Arabic / PT151(1251)

Input buffer
USB/USB+BT: 128 Kbytes   |   USB+Lan: 256 Kbytes
NV Flash1M bytes
Power
Power adaptor
AC 100V/240V, 50~60Hz
Power sourceDC 9V / 2A
Cash drawerDC 12V / 1A
Physical characteristics
Weight
0.8kg
Dimensions169.95 ×120 × 119.92mm
Environmental Conditions
Operation environmentTemperature (0~45℃)  humidity(10~80%)
Storage environmentTemperature(-10~60℃) humidity(10~90%)
Physical Reliability
Printer head life50KM
Software
Emulation
ESC/POS
DriverWindows/JPOS/Linux/Android/Mac
SDKiOS / Android / Windows
