76IIN

Product Overview

part.1

Black mark orientation, supports invoice printing function

part.2

Support bi-directional printing

part.3

Freshness outstanding design, easy to operate

part.4

GB18030 simplified Chinese, support traditional Chinese and various international languages

part.5

Various interfaces, multiply choices

Product Specification

Printing
Printing method	9-Pin serial impact dot-matrix printing
Printing width	63.5mm
Print Resolution	84 dpi
Printing speed	4.5 line/s Max.
Interface	Parallel / USB/ USB+Lan
Print paper	75.5±0.5mm Φ65mm
Character size	ANK，Font A: 1.6×3.1mm（9×9 matrix） Font B: 1.2×3.1mm（7×9 matrix）Chinese,traditional Chinese: 2.7×2.7mm（16×16 matrix）
Column number	Font A - 33 columns /Font B - 40 columns / Chinese, traditional Chinese - 22 columns
Character
Extension character sheet	PC437/Katakana/PC850/PC860/PC863/PC865/WPC1252/PC866/PC852/PC858
Software
Driver	Windows /Linux /Mac
Utility	Windows
SDK	Windows/ Android
Power
Power adaptor	Input：AC 110V/220V, 50～60Hz, Output: DC 24V/2.5A
Printer input	DC 24V/2.5A
Cutter
Auto cutter	Partial
Physical characteristics
Gross weight	1.46 KG
Dimensions	230150138mm
Environmental Requirements
Work environment	0～45℃, 10～80% RH
Storage environment	-10～60℃, 10～90% RH（no condensation）
Reliability
Printer head life	10 Million Lines
