P201A

Brand name: Xprinter
Place of Origin: China
Model Number: XP-P201A
Material: ABS
Certification: CCC, CE, FCC, RoHS, KC, SAA, BIS, BSMI
OEM Availability: Yes
Payment Term: T/T, L/C
EMAIL INQUIRY

Product Overview

Support both receipt printing and label printing	Support NFC function
Support QR code	70mm/s print speed
2550mAh battery life longer than other products

Product Specification

Printer Model	XP-P201A
Print mode	Label print mode	Receipt print mode
Printing method	Direct Thermal
Max.print speed	70 mm/s Max.	70 mm/s
Max.print width	48 mm	48 mm
Media type	Thermal paper roll /Thermal adhesive paper	Thermal paper
Media width	20~56mm	58mm
Label roll diameter	≤50mm	≤50mm
Fonts/Graphics/Symbologies
Graphics	Monochrome PCX, BMP files can be downloaded to flash and DRAM	Support bitmap printing with different density and download bitmap
1D Bar code	1D barcode: CODE128 / EAN128 / ITF / CODE 2 of 5 Interleaved / CODE39 / CODE39C / CODE39S / CODE93 / EAN13 / EAN13+2 / EAN13+5 / EAN8 / EAN8+2 / EAN8+5 / CODABAR / POSTNET / UPC-A / UPCA+2 / UPCA+5 / UPCE / UPCE+2 / UPCE+5 / MSI / MSIC / PLESSEY / ITF14 / EAN14	1D bar code: UPC-A / UPC-E / JAN13(EAN13) / JAN8(EAN8) / CODE39 / ITF / CODABAR / CODE93 / CODE128
2D Bar code	QRCODE	QRCODE
Character	Font 0 to Font8	ASCII character set,Font A: 12x24,Font B: 9x17, GB18030/BIG5/KSC5601,CHN: 24*24
Emulaion	TSPL	ESC/POS
Enlarged/Rotation	It can be enlarged 1-8 times horizontally and longitudinally, and it can be rotated: 0° / 90° / 180° / 270°
Performance Features
Interface	USB+Bluetooth
Print head temperature detection	Thermistor
Cover open detection	Micro Switch
Media detection	Photoelectric Sensors
Storage	Flash 576 kb
Physical Features
Dimension	123.38 x 91.93 x 62.2mm
Weight	0.323kg
Output	DC 5V/2A
Battery	7.2V/2550mAh
Operation system	Windows / Android / iOS
Operation environment	0～45℃, 10～80% RH no condensing
Storage environment	-10～60 ℃, ≤93% RH (40℃) no condensing
