  • Brand name: Xprinter
    Place of Origin: China
    Model Number: XP-P201A
    Material: ABS
    Certification: CCC, CE, FCC, RoHS, KC, SAA, BIS, BSMI
    OEM Availability: Yes
    Payment Term: T/T, L/C
  • EMAIL   INQUIRY

Product Overview


Support both receipt printing and label printingSupport NFC function
Support QR code70mm/s print speed
2550mAh battery life longer than other products


Product Specification


Printer ModelXP-P201A
Print modeLabel print modeReceipt print mode
Printing method
Direct Thermal
Max.print speed70 mm/s Max.70 mm/s
Max.print width48 mm48 mm
Media type
Thermal paper roll /Thermal adhesive paperThermal paper
Media width20~56mm58mm
Label roll diameter

≤50mm

≤50mm
Fonts/Graphics/Symbologies
GraphicsMonochrome PCX, BMP files can be downloaded to flash and DRAMSupport bitmap printing with different density and download bitmap
1D Bar code1D barcode: CODE128 / EAN128 / ITF / CODE 2 of 5 Interleaved / CODE39 / CODE39C / CODE39S / CODE93 / EAN13 / EAN13+2 / EAN13+5 / EAN8 /  EAN8+2 / EAN8+5 / CODABAR / POSTNET / UPC-A / UPCA+2 / UPCA+5 / UPCE / UPCE+2 / UPCE+5 / MSI / MSIC / PLESSEY / ITF14 / EAN141D bar code: UPC-A / UPC-E / JAN13(EAN13) / JAN8(EAN8) / CODE39 / ITF / CODABAR /  CODE93 / CODE128
2D Bar codeQRCODEQRCODE
CharacterFont 0 to Font8ASCII character set,Font A: 12x24,Font B: 9x17,
               GB18030/BIG5/KSC5601,CHN: 24*24
EmulaionTSPLESC/POS
Enlarged/RotationIt can be enlarged 1-8 times horizontally and longitudinally, and it can be rotated: 0° / 90° / 180° / 270°
Performance Features
Interface

USB+Bluetooth

Print head temperature
detection
Thermistor
Cover open detectionMicro Switch
Media detectionPhotoelectric Sensors
StorageFlash 576 kb
Physical Features
Dimension123.38 x 91.93 x 62.2mm
Weight0.323kg
Output
DC 5V/2A
Battery7.2V/2550mAh
Operation system
Windows / Android / iOS
Operation environment0~45℃, 10~80% RH  no condensing
Storage environment-10~60 ℃, ≤93% RH (40℃)  no condensing
