Product Overview
| ● Small size and low power consumption | ● Support prompt and error alarm function |
| ● Support IAP online upgrade | ● Support Linux system and OPOS driver |
Product Specification
| Printing | ||
| Printing method | Direct thermal | |
| Media width | 79.5±0.5mm / φ 80 mm | |
| Print width | 72mm | |
| Column capacity | 576 dots/line or 512 dots/line | |
| Printing speed | 230mm/s | |
| Interface | USB / USB+Serial(Optional: USB+Bluetooth/USB+Wifi) | Lan(Optional:USB+Lan) |
| Line spacing | 3.75mm (Adjustable by commands) | |
Character size | ANK，Font A：1.5×3.0mm（12×24 dots） Font B：1.1×2.1mm（9×17 dots） Chinese,traditional Chinese:3.0×3.0mm（24×24 dots） | |
| Barcode Character | ||
| Extension character sheet | PC437（Standard Europe）、Katakana、PC850（Multilingual）、PC860（Portuguese）、PC863（Canadian）、PC865（Nordic）、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866（Cyrillic#2）、PC852（Latin2）、PC858、IranII、Latvian、Arabic、PT151（1251） | |
| 1D Barcode | UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/CODABAR/CODE93/CODE128 | |
| 2D Barcode | /// | QR CODE |
| Input buffer | 64 Kbytes | 256 Kbytes |
| NV Flash | 256 Kbytes | |
| Power | ||
| Power adaptor | Input: AC 100/240V, 50～60Hz | |
| Printer input | DC 24V/2.5A | |
| Cash drawer | DC 24V/1A | |
| Physical characteristics | ||
| Weight | 0.78 KG | |
| Dimensions | 166×126.5×128mm (D×W×H) | |
| Environmental Requirements | ||
| Work environment | Temperature (0～45℃) humidity(10～80%) | |
| Storage environment | Temperature(-10～60℃) humidity(10～90%) | |
| Reliability | ||
| Auto cutter | Partial | |
| Cutter life | 1.5 million cuts | |
| Printer head life | 150 KM | |
| Software | ||
| Emulation | ESC / POS | |
| Driver | Windows / Linux / Mac OS / Android | |
