  • E200L/ E260L
  • E200L/ E260L
E200L/ E260L E200L/ E260L

E200L/ E260L

  • Brand name: Xprinter
    Place of Origin: China
    Model Number: XP-E200L/ XP-E260L
    Material: ABS
    Certification: CCC, CE, FCC, RoHS, KC, SAA, BIS, BSMI
    OEM Availability: Yes
    Payment Term: T/T, L/C
  • EMAIL   INQUIRY

Product Overview





  • XP-E200L/XP-E260L with horizontal, wall-mounting design, which is easy drop-in paper loading, high printing speed Max. 260mm/s, supports QR code, and OPOS driver available for all .

  • XP-E200L/XP-E260L with horizontal, wall-mounting design, which is easy drop-in paper loading, high printing speed up to 260mm/s, OPOS driver available.

●  Wall mount available●  High-speed printing in its class
●  Strong Systems Compatibility : Windows/JPOS/Linux/Android/Mac/OPOS●  Support QR code and PDF417 printing




Product Specification


   Printer input voltage

ModelXP-E200LXP-E260L
Printing
Printing methodDirect thermal
Paper width79.5±0.5mm
Print width72mm/ 76mm/ 80mm/ 64mm/ 48mm/ 52mm
Column capacity576 dots/line(adjustable by command)
Printing speed200 mm/s Max.260 mm/s Max.
Interface

USB+Lan/USB+Serial

(Optional: Bluetooth/Wifi)

USB+Serial+Lan
Line spacing3.75mm (Adjustable by commands)

Column number

80mm paper: Font A - 42 columns or 48 columns/Font B - 56 columns or 64 columns/
Chinese,traditional Chinese - 21 columns or 24 columns

Character size

ANK,Font A:1.5×3.0mm(12×24 dots) Font B:1.1×2.1mm(9×17 dots) Chinese,traditional Chinese:3.0×3.0mm(24×24 dots)
Cutter
Auto cutterPartial
Barcode Character
Extension character
sheet
PC347(Standard Europe)、Katakana、PC850(Multilingual)、PC860(Portuguese)、PC863(Canadian-French)、PC865(Nordic)、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866(Cyrillic#2)、PC852(Latin2)、PC858、IranII、Latvian、Arabic、PT151(1251)
Barcode typesUPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128
2D BarcodeQR Code / PDF417
Input buffer128 Kbytes
NV Flash256 Kbytes
Power
Power adaptor

Input:AC  100-240V, 50~60Hz

Output: DC 24V/2.5A

Printer inputDC 24V/2.5A
Cash drawerDC 24V/1A
Physical characteristics
Weight1.12 Kg
Dimensions192×140×140mm (D×W×H)
Environmental Requirements
Operation environmentTemperature 0~45 °C  humidity: RH 10~80%
Storage environmentTemperature -10~60℃ humidity: RH 10~90%
Reliability
Cutter life1.5 million cuts
Printer head life150 KM
Software
Emulation
ESC/POS
Driver

Windows/JPOS/Linux/Android/Mac/OPOS

UtilityWindows & Linux test Utility
SDKiOS/Android/Windows
