Product Overview
| ● Multiple interface connections, auto-cutter, wall mountable | ● Support both 58mm and 80mm width paper. (300mm speed support) |
| ● Queuing function, re-printing function. (USB+Lan, USB+Serial+Lan) | ● lAP online upgrade, printer head over-temperature protection function, and cutter anti-jam function |
| ● Support a variety of 1D barcode and 2D barcode printing. | ● Compatible with ESC/POS commands |
Specification
| Model | XP-Q801K | ||
| Printing | |||
| Printing method | Direct thermal | ||
| Paper width | 80mm | ||
| Column capacity | 576 dots/line or 512 dots/line | ||
| Printing speed | 230 mm/s | 260 mm/s | 300 mm/s |
| Interface | USB / USB+Lan(Optional:BT/WiFi); USB+Serial; | USB+Serial+Lan(Optional:BT / WiFi) | USB+Serial+Lan(Optional:BT / WiFi) |
| Line spacing | 3.75mm (Adjustable by commands) | ||
Column number | 80mm paper: Font A - 42 columns or 48 columns/Font B - 56 columns or 64 columns/ Chinese,traditional Chinese - 21 columns or 24 columns | ||
Character size | ANK，Font A：1.5×3.0mm（12×24 dots） Font B：1.1×2.1mm（9×17 dots） Chinese,traditional Chinese:3.0×3.0mm（24×24 dots） | ||
| Cutter | |||
| Auto cutter | Partial | ||
| Barcode Character | |||
| Extension character sheet | PC347（Standard Europe）、Katakana、PC850（Multilingual）、PC860（Portuguese）、PC863（Canadian-French）、PC865（Nordic）、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866（Cyrillic#2）、PC852（Latin2）、PC858、IranII、Latvian、Arabic、PT151（1251） | ||
| Barcode types | UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/CODABAR/CODE93/CODE128 | ||
| 2D Barcode | QR Code | QR Code / PDF417 | QR Code / PDF417 |
| Input buffer | USB / USB+Serial: 96 Kbytes USB+Lan : 256 Kbytes | 256 Kbytes | 4096 Kbytes |
| NV Flash | 256 Kbytes | 256 Kbytes | 256 Kbytes |
| Power | |||
| Power adaptor | Input: AC 100-240V/50~60Hz | ||
| Printer input | DC 24V/2.5A | ||
| Cash drawer | DC 24V/1A | ||
| Physical characteristics | |||
| Weight | 1.0 KG | ||
| Dimensions | 194.5*145*146.4mm (D×W×H) | ||
| Environmental Requirements | |||
| Work environment | Temperature (0～45℃) humidity(10～80%) | ||
| Storage environment | Temperature(-10～60℃) humidity(10～80%) | ||
| Reliability | |||
| Cutter life | 1.5 million cuts | ||
| Printer head life | 150 KM | ||
| Software | |||
| Emulation | ESC/POS | ||
| Driver | Windows/JPOS/OPOS/Linux/Android/Mac | ||
| Utility | Windows & Linux test Utility | ||
| SDK | iOS/Android/Windows | ||
