Specifications
Printer Model | XP-TT426B |
Printing Features | |
Resolution | 203 DPI |
Printing method | Thermal Transfer / Direct Thermal |
Max.print speed | 127 mm/s Max. |
Max.print width | 108 mm (4.25") |
Max.print length | 1778 mm (70") |
Media | |
Media type | Continuous, gap, black mark, fan-fold and punched hole |
Media width | 25.4-118mm (1.0”-4.6”) |
Media thickness | 0.06~0.254 mm (2.36~10mil) |
Media core diameter | 25.4 ~ 76.2 mm (1 "~ 3 ") |
Label length | 10 - 1778 mm(0.39" ~ 70" ) |
Label roll capacity | 127 mm (5“) OD (External diameter) |
Ribbon capacity | Max.300m |
Ribbon width | 110 mm |
Ribbon core | 25.4 mm (1") |
Performance Features | |
Processor | 32-bit CPU |
Memory | 8MB Flash Memory/ 8MB SDRAM/ Flash memory can be expanded Max.4Gb |
Interface | Stardard version: USB Optional:Lan/WIFI/Bluetooth/TF card |
Sensors | ①Gap sensor ②Cover opening sensor ③Black mark sensor ④Ribbon sensor |
Fonts/Graphics/Symbologies | |
Internal fonts | 8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software. |
1D barcode | Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST |
2D barcode | PDF-417, Maxicode, DataMatrix, QR code, Aztec |
Rotation | 0°、90°、180°、270° |
Emulation | TSPL、EPL、ZPL、DPL |
Physical Features | |
Dimension | 299 mm (D) x 235 mm (W) x 198.3 mm (H) |
Weight | 2.55kg |
Reliability | |
Print head life | 30 km |
Software | |
Driver | Windows/Linux/Mac |
SDK | Windows/Android/iOS |
Power supply | |
Input:AC 110-240V,1.8A, 50-60Hz | |
Output:DC 24V, 2.5A, 60W | |
Options | |
Factory Options | ① Built-in Ethernet server (10/100 Mbps); ② RS-232C (2400-115200 bps) communication interface; ③ Cutter ④ Peeling machine ⑤ Bluetooth module ⑥ WiFi module |
Dealer Options | ①External paper roll holder and 1 "paper roll; ②Extension board for external paper roll holder |
Environmental Conditions | |
Operation environment | 5 ~ 40°C(41~104°F),Humidity: 25 ~ 85% non-condensing |
Storage environment | -40 ~ 60°C(-40~140°F),Humidity:10 ~ 90% non-condensing |
