P322B

Product Overview

Support direct USB charging	50mm diameter paper roll
OLED screen available	TSPL, EPL, ZPL, DPL, CPCL, ESC/POS command compatible
2500mAh battery life longer than other products

Product Specification

Model	XP-P322B
Printing Features
Resolution	203 DPI
Printing method	Direct Thermal
Max.print speed	Max. 70mm (2.7") / s
Max.print width	72 mm (2.8")
Max.print length	1778 mm (70")
Media
Media type	Continuous, gap, black mark
Media width	25.4 mm ~ 76 mm
Media thickness	0.06 mm ~0.16 mm
Performance Features
Processor	32-bit CPU
Memory	8MB Flash Memory/ 8MB SDRAM
Interface	Stardard version: USB+Bluetooth Optional:USB+WIFI
Screen	OLED (0.96") Resolution: 128*64 pix
Sensors	①Gap sensor ②Cover opening sensor ③Black mark sensor
Fonts/Graphics/Symbologies
Internal fonts	8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software.
1D bar code	Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST
2D bar code	PDF-417, Maxicode, DataMatrix, QR code
Rotation	0°、90°、180°、270°
Emulaion	TSPL、EPL、ZPL、DPL、CPCL、ESC/POS
Physical Features
Dimension	120×112×60mm (D×W×H)
Weight	400 g
Reliability
Print head life	30 km
Software
Operation system	Windows/Android/iOS
SDK	Windows/Android/iOS
Power supply
USB	DC 5V/2A
Battery	2500mAh
Environmental Conditions
Operation environment	5 ~ 40°C（41~104°F），Humidity: 25 ~ 85% no condensing
Storage environment	-40 ~ 60°C（-40~140°F），Humidity: 10 ~ 90% no condensing
