P502A

Product Overview

● Multiple 1D barcode printing	● QR CODE/PDF 417 2D barcode printing
● NV LOGO download picture printing	● Compatible with Windows/Linux/Android/iOS systems
● Multiple languages available

Product Specification

Model	XP-P502A
Printing Features
Printing method	Direct thermal
Paper width	58 mm
Line spacing	3.75mm (Adjustable by commands)
Print width	48 mm
Max.print speed	Max.70 mm/s
Performance Features
Interfaces	USB+Bluetooth(1+1)
Printhead life	50 KM
CPU storage	128 Kbytes
NV Flash	4M bytes
Emulation	ESC/POS
Fonts/Graphics/Symbologies
Character size	ANK，Font A：1.5×3.0mm（12×24 dots）Font B：1.1×2.1mm（9×17 dots） simplified/traditional Chinese：3.0×3.0mm（24×24 dots）
Barcode types	1D: UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/CODABAR/CODE93/CODE128 2D: QRCODE / PDF417
Extended character sheet	PC347（Standard Europe）、Katakana、PC850（Multilingual）、PC860（Portuguese）、PC863（Canadian-French）、PC865（Nordic）、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866（Cyrillic#2）、PC852（Latin2）、PC858、IranII、Latvian、Arabic、PT151（1251）
Rotation	0°、90°、180°、270°
Physical Features
Dimension	12491.0158.44mm (LWH)
Weight	0.237 kg
Compatible systems
Systems	Windows / Linux / Android / iOS
Power supply
Battery	3.7V / 2600mAh
Charging input	DC 5V / 1A
Environmental Conditions
Operation environment	0～45℃，10～80%RH no condensing
Storage environment	-10～60 ℃，≤10~90% RH no condensing
