Product Parameters
2D wireless scanner
Product features
● Adopting the most advanced decoding algorithm technology, it can interpret various complex one-dimensional and two-dimensional codes
● Support scanning barcodes on mobile phones and computers, and can quickly realize WeChat and Alipay payment
● Ergonomic design, comfortable operation, and not easy to fatigue after long-term operation
● The whole machine is fully dust-proof to meet more scene applications
● Red LED indicator and loud buzzer prompt sound, fast feedback code reading experience
● Support multiple communication interfaces, plug and play
Application:
Mainly used in commerce, payment, medical and health, tobacco, etc.
Technical parameters
Working parameters | |
Image (pixel) | 640 pixels(H)*480 pixels(v) |
Product features | 2.4G MHZ with a transmission distance of 150M in open space (indoor transmission distance is generally 25M-50M depending on the structure and environment), built-in 1800MAH battery, use time 8-10 hours, built-in storage with inventory function, can store up to 5000 barcodes |
Light source | Aiming:617 nm LED ;illumination:6500K LED |
Reading code system | 2D： QR Code, Data Matrix, PDF417 1D： UPC/EAN/JAN,UPC-A & UPC-E,EAN-8 & EAN-13, JAN-8 &JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128,Code 93,Interleaved 2 of 5 (ITF),Addendum 2 of 5, Matrix 2 of 5,Standard 25,IATA Code,Plessey,MSI/Plessy, China Postal Code,Code 32 (Italian Pharmacode),GS1-DataBar TM （RSS） ,（RSS 14,RSS-Limited, RSS-Expanded）,AIM-128. |
Scanning distance | 25-180mm @ UPC/EAN 13mil PCS=90%；20-250mm @ QR 20mil PCS=100% |
Scanning angle | 65° elevation/30° rotation/60° deflection |
Field of view | 34° horizontal, 28° vertical |
Reading accuracy | ≥ 4mil |
Printing contrast | ≥25% |
Indication method | Red LED, buzzer |
Communication interface | TTL-232, USB (HID-KBW, virtual serial port) |
Scanning | 300 times/second |
Physical parameters | |
Dimensions | 171x70x96MM |
Wire length | 1.6 meters straightened |
Shell material | flame retardant material |
Trigger mode | key trigger, inductive reading, continuous reading |
Power supply parameters | |
Input voltage | 5VDC±10% |
Working current | 200mA |
Environmental parameters | |
Working temperature | -20℃~+60℃ |
Working humidity | 5%~95%non-condensing |
Storage temperature | -40℃~+70℃ |
Ambient brightness | 0~100,000Lux |
Accessories: Charging cable x1, instruction manual, product certificate, warranty card x1, receiver x1
Related Products
Packaging & Shipping
Company Profile
Dahema is a high-tech enterprise specializing in the research, development and application of barcode automatic identification technology. Since its establishment in 2011, Bangyue has always focused on the promotion, application and development of Chinese barcode technology, and has cultivated a number of technical backbones and sales elites in years of technical research and practice. The good pre-sales and after-sales service has made Bangyue Barcode enjoy a high reputation among peers and customers from all walks of life. With professional talent advantages and rich practical experience, we have a stable customer base in retail, public utilities, industrial manufacturing, logistics distribution and other fields, accumulated valuable customer service experience, and won the trust and love of customers.
We serve customers with the tenet of "integrity, professionalism, responsibility and continuity". We have won the trust and support of our customers in various countries around the world, and we continue to adhere to the attitude of learning to serve our customers.
FAQ
Q.:Are you a factory or foreign trade company?
A: We are a factory located in Guangzhou City,Guangdong province.
Q: Samples are available for customers testify?
A: Please no doubt with that, of course free samples will offerable for every of our clients.
Q: What's your leading time regarding bulk production?
A: Generally for 3-10 workding days, small productions keep it withing 1-3 working days.
Q: If do bulk production, will make the quality same as the sampling confirmation?
A: Definitely. Quality is the first thing we have to gurantee for our customers, always will go through for a strict line of inspectation to ensure all goods are in good condition.
Q: What about the inferior quality products?
A: Please be sure that we'll do our best to make up the poor quality products if caused by us, but if made by force majeure or shipping in tansit, we still will strive for the biggest benefits for you.
Contact Us
Tel：+86 020 2983 0664
Mobile：+86-13924290301
E-mail: sales@gzdhm.cn
Skype: live:sales_47080
Whatsapp: +86-13924290301
